Grumman TBF Avenger

The Grumman TBF Avenger (designated TBM for aircraft manufactured by General Motors ) was a torpedo bomber developed initially for the United States Navy and Marine Corps, and eventually used by several air or naval arms around the world. It entered U.S. service in 1942, and first saw action during the Battle of Midway.

Design and development

Douglas' TBD Devastator, the U.S. Navy's main torpedo bomber introduced in 1935, was obsolete by 1939. Bids were accepted from several companies but Grumman's TBF design was selected as the TBD's replacement. Designed by Leroy Grumman, its first prototype was called the XTBF-1. Although one of the first two prototypes crashed near Brentwood, New York , rapid production continued.

Grumman's first torpedo bomber was the heaviest single-engine aircraft of World War II, and only the USAAF's P-47 Thunderbolt came close to equalling it in maximum loaded weight among all single-engined fighters, only being some 400 lb (181 kg) lighter than the TBF, by the end of World War II. The Avenger was the first design to feature a new wing-folding mechanism created by Grumman, intended to maximize storage space on an aircraft carrier; the F4F-4 and later models of Wildcat received a similar folding wing and the F6F Hellcat (both designed by Grumman) employed this mechanism as well. The engine used was the Wright R-2600-20 (which produced 1,900 hp /1,417 kW). The aircraft took 25 gallons of oil and used one gallon per minute at start-up. There were three crew members: pilot, turret gunner and radioman/bombardier/ventral gunner. One .30 caliber machine gun was mounted in the nose, a .50 caliber (12.7 mm) gun was mounted right next to the turret gunner's head in a rear-facing electrically powered turret, and a single .30 caliber hand-fired machine gun mounted ventrally (under the tail), which was used to defend against enemy fighters attacking from below and to the rear. This gun was fired by the radioman/bombardier while standing up and bending over in the belly of the tail section, though he usually sat on a folding bench facing forward to operate the radio and to sight in bombing runs. Later models of the TBF/TBM dispensed with the nose-mounted gun for one .50 caliber gun in each wing per pilots' requests for better forward firepower and increased strafing ability. There was only one set of controls on the aircraft, and no access to the pilot's position from the rest of the aircraft. The radio equipment was massive, especially by today's standards, and filled the whole glass canopy to the rear of the pilot. The radios were accessible for repair through a "tunnel" along the right hand side. Any Avengers that are still flying today usually have an additional rear-mounted seat in place of the radios, which increases crew to four.

The Avenger had a large bomb bay, allowing for one Bliss-Leavitt Mark 13 torpedo, a single 2,000 pound (907 kg) bomb, or up to four 500 pound (227 kg) bombs. The aircraft had overall ruggedness and stability, and pilots say it flew like a truck, for better or worse. With its good radio facilities, docile handling, and long range, the Grumman Avenger also made an ideal command aircraft for Commanders, Air Group (CAGs). With a 30,000 ft (10,000 m) ceiling and a fully-loaded range of 1,000 mi (1,610 km), it was better than any previous American torpedo bomber, and better than its Japanese counterpart, the obsolete Nakajima B5N "Kate". Later Avenger models carried radar equipment for the ASW and AEW roles. Although improvements in new types of aviation radar were soon forthcoming from the engineers at MIT and the electronic industry, the available radars in 1943 were very bulky, because they contained vacuum tube technology. Because of this, radar was at first carried only on the roomy TBF Avengers, but not on the smaller and faster fighters.

Escort carrier sailors referred to the TBF as the "turkey" because of its size and maneuverability in comparison to the F4F Wildcat fighters in CVE airgroups.

Operational history

Avenger Mk

.IRN designation of the TBF-1, 400 delivered.

Avenger Mk

.IIRN designation of the TBM-1/TBM-1C, 334 delivered.

Avenger Mk

.IIIRN designation of the TBM-3, 222 delivered

Avenger Mk

.IVRN designation of the TBM-3S, 70 cancelled

Avenger AS4

RN designation of the TBM-3S, 100 delivered postwar

Avenger AS3

Modified by RCN for anti-submarine duty, dorsal gun turret removed, 98 built

Avenger AS3M

AS3 with magnetic anomaly detector boom added to rear fuselage

Notable incident

The most famous incident involving the Avenger aircraft was the disappearance of Flight 19, a squadron of five Avengers lost in December 1945 over the Bermuda Triangle .

Aircraft on display

*A TBM is on display in the hangar deck of the at the Patriot's Point Naval and Maritime Museum in Charleston, South Carolina .

*A TBM is also on display at the National Museum of the Pacific War at the Pacific Combat Zone in Fredericksburg, Texas .

*A TBM-3E is on display on the hangar deck of the at the Intrepid Sea-Air-Space Museum at Pier 86 in New York, New York . It is on loan from the National Museum of Naval Aviation in Pensacola, Florida .

*A TBM-3E is on display in the hangar deck of the in Alameda, California .

*A TBM-3E is on display in the Cavanaugh Flight Museum at Addison Airport in Dallas, Texas .

*A TBM Avenger is on display at the Tillamook Air Museum in Tillamook, OR.

* A TBM-3E Avenger is on display at the Quonset Air Museum , North Kingstown, Rhode Island .

*A TBM-3E is on display at the Cradle of Aviation Museum , Garden City, Long Island, New York . It is on loan from the Friends For Long Island's Heritage, sponsored by Mrs.William P. Schwendler.

*A flying TBM-3E is on display at the CAF Rocky Mountain Wing Museum at the Grand Junction Regional Airport in Grand Junction, Colorado . This authentic warbird is on exhibit and flys at western airshows with paid flights for the public.

* A TBF Avenger is on display at Museum of Transport and Technology , Western Springs , Auckland , New Zealand ; and one of four in New Zealand.

* A TBM-3E Avenger is on display in the hangar deck of the museum in Corpus Christi, TX .

* An airworthy TBM-3E that is flown regularly is on display at the Planes of Fame Air Museum in Chino, CA.
